APC Rack PDU 9000 Switched, ZeroU, 32A, 230V

MFG #: APDU9953
ATECH #: APCAPDU9953
UPC : 731304356271
Manufacturer : APC
If you don't have an account, Become a Reseller!

Marketing Information

It is a switched rack PDU with a maximum current capacity of 32A and an input voltage of 200-240V. It features 21 IEC 60320 C13 outlets and 3 IEC 60320 C19 outlets, connected via an IEC 60309 32A 2P +E input connection. The PDU has a ZeroU form factor and a cord length of 10 feet (3.05 meters). It supports remote monitoring and user-defined alarms, with outlet-level on or off switching capabilities. The unit is UL Listed and CSA certified, ensuring high safety and performance standards.


Technical Specifications

  • Color: Black
  • Product or component type: PDU
  • PDU type: Switched
  • Cord length: 3 m
  • Number of cables: 1
  • Provided equipment: Installation guide; Rack mounting brackets; Safety guide
  • Input Voltage: 200...240 V
  • Height: 1829 mm
  • Width: 56 mm
  • Output Voltage: 200...240 V
  • Depth: 46 mm
  • Net weight: 7.34 kg
  • Mounting location: Side
  • Mounting preference: No preference
  • Input Plug Type: IEC 60309 32 A 2P + E
  • Mounting mode: Not rack-mountable
  • Rack units: 0U
  • USB compatible: No
  • Mounting position: Vertical
  • Communication port protocol: SNMP; Redfish
  • permissible voltage: 220…240 V
  • Max line current: 32 A
  • Input current limits: 32 A
  • Load capacity: 7400 VA
  • Network frequency: 50/60 Hz
  • Outlet type and quantity: 21 IEC 60320 C13; 3 IEC 60320 C19
  • Communication network type: 10/100/1000BASE-T
  • Product certifications: VDE; EAC; RCM
  • Standards: EN 55022 class A; EN 55024; EN 61000-3-2; EN 61000-3-3
  • Ambient air temperature for operation: -5…60 °C
  • Relative humidity: 5…95 %
  • Operating altitude: 0...10000 ft
  • Ambient air temperature for storage: -25…65 °C
  • Storage Relative Humidity: 5…95 %
  • Storage altitude: 0…15240 m
Net Weight: 21.94 lbs
UOM: EACH
