Technical Specifications

• Color: Black
• Product or Component Type: PDU
• PDU Type: Switched
• Cord length: 12 ft (3.7 m)
• Number of cables: 1
• Provided Equipment: Documentation CD; Installation guide; Rack Mounting brackets
• Input Voltage: 200 V; 208 V; 230 V
• Height: 3.50 in (8.9 cm)
• Width: 17.48 in (44.4 cm)
• Output Voltage: 208 V
• Depth: 10.00 in (25.4 cm)
• Product Weight: 13.93 lb(US) (6.32 kg)
• Mounting Location: Front; Rear
• Mounting preference: No preference
• Input Plug Type: NEMA L6-30P
• Mounting Mode: Rack-mounted
• Rack units: 2U
• Mounting position: Horizontal
• Line Rated Current: 24 A
• permissible voltage: 200…240 V
• Input current limits: 30 A
• Load Capacity: 4992 VA
• Input Frequency: 50/60 Hz
• Outlet type and quantity: 16 IEC 60320 C13
• Product Certifications: cUL Listed; CSA; Industry Canada; PSE; UL Listed
• Standards: FCC Part 15 class A; ICES-003; UL 60950
• Ambient air temperature for operation: 32…113 °F (0…45 °C)
• Relative Humidity: 0…95 %
• Operating altitude: 0...10000 ft
• Ambient Air Temperature for Storage: -13…149 °F (-25…65 °C)
• Storage Relative Humidity: 0…95 %
• Storage altitude: 0…50000 ft (0.0000000000…15240.0000000000 m)
• Category: 80230-IG SEBA TO SEUSA
• Discount Schedule: BMS1
• GTIN: 731304331605
• Returnability: No
• Country of origin: PH
• Unit Type of Package 1: PCE
• Number of Units in Package 1: 1
• Package 1 Height: 5.75 in (14.6 cm)
• Package 1 Width: 20.24 in (51.4 cm)
• Package 1 Length: 20.24 in (51.4 cm)
• Package 1 Weight: 18.43 lb(US) (8.36 kg)
• Warranty: 2 years repair or replace
