Technical Specifications

• Color: Black
• Product or Component Type: PDU
• PDU Type: Basic
• Cord length: 10 ft (3.05 m)
• Number of cables: 1
• Provided Equipment: Installation guide; Rack Mounting brackets; Toolless Mounting Kit
• Input Voltage: 200 V; 208 V; 230 V
• Height: 63.7 in (161.9 cm)
• Width: 2.2 in (5.6 cm)
• Output Voltage: 208 V
• Depth: 1.7 in (4.4 cm)
• Net Weight: 10.71 lb(US) (4.86 kg)
• mounting location: Side
• Mounting preference: No preference
• Input Plug Type: NEMA L6-20P
• Mounting Mode: Rack-mounted
• Rack units: 0U
• Mounting position: Vertical
• Line Rated Current: 16 A
• Input current limits: 20 A
• Load Capacity: 3300 VA
• Input Frequency: 50/60 Hz
• Outlet type and quantity: 20 IEC 60320 C13; 4 IEC 60320 C19
• Product Certifications: cUL Listed; UL Listed
• Standards: CSA C22.2 No. 60950-1-03; UL 60950-1
• Category: 80230-IG SEBA TO SEUSA
• Discount Schedule: BMS1
• GTIN: 731304207931
• Returnability: No
• Country of origin: IN
• Unit Type of Package 1: PCE
• Number of Units in Package 1: 1
• Package 1 Height: 84.02 in (213.4 cm)
• Package 1 Width: 5.0000000000 in (12.7 cm)
• Package 1 Length: 6.0 in (15.2 cm)
• Package 1 Weight: 12.72 lb(US) (5.77 kg)
• Warranty: 2 years repair or replace
