OWC, U2 ShuttleOne, NVMe M.2 to 2.5-inch, U.2 SSD Adapter

MFG #: OWCU2SHTLONE
ATECH #: OWCU2SHTLONE
UPC : 810586037105
Manufacturer : OTHER WORLD COMPUTING
If you don't have an account, Become a Reseller!

Marketing Information

The OWC U2 ShuttleOne brings U.2 SSD performance and capacity to the mainstream with a flexible, easy to use “build your own” heat dissipating full metal adapter. Performance enthusiasts, IT admins, M&E pros, gamers, and more can now use a readily available and affordable NVMe M.2 “blade” style SSD in a 2.5-inch U.2 bay. Whether you have a U.2 bay equipped server, workstation, gaming rig, or external drive; the OWC U2 ShuttleOne gives you access to a new world of storage possibilities.


Technical Specifications

  • Drive Bays: 1 bay supporting: M.2 SSDs; Supports single-sided and double-sided M.2 2230, M.2 2242, M.2 2260, M.2 2280 "M Key" drives; Supports NVMe M.2 SSDs with 2230, 2242, 2260, and 2280 form factor and "M Key" connector type. Single- and double-sided SSDs are supported.; NVMe SSDs with a heatsink will not fit and are not supported.
  • Form Factor: 2.5-inch U.2 (SFF-8639)
  • Drive Interface: PCIe 4.0 x4
  • Mac OS Compatibility: Requires additional hardware, please see the 'Other Requirements' section for more details.
  • PC OS Compatibility: Varies by host device
  • Other Requirements: Requires a NVMe (PCIe) enabled U.2 backplane/connector on a host system or enclosure such as OWC ThunderBay Flex 8 (top 4 bays only, top-left recommended), OWC Flex 1U4, OWC Mercury Helios 3S with U.2 NVMe Interchange System.
  • Dimensions: Height: 0.9 cm (0.4 in); Length: 10.1 cm (4.0 in); Width: 7.0 cm (2.8 in)
  • Humidity: Operating: 5% to 95% non-condensing; Non-Operating: 5% to 95% non-condensing
Net Weight: 0.30 lbs USPS OK
UOM: EACH
